CMP40L Liquid(water) micro pumps are well suited for transferring and evacuating neutral or corrosive liquid as well as water with low flow and low pressure.

Technical Features
1.Uncontaminated flow.
2.Non-metallic construction.
3.Compact size.
4.Maintaince free.
5.High level of water tightness thanks to the closed diaphragm surface and special sealing system.
6.Can operate in any installed position.



Various models

Type Voltage Free flow Max vacuum Max pressure Current Size
CMP40L 12V DC 1 L/min -300mbar 4 bar 0.8A 40*66*95mm
CMP40L 24V DC 1 L/min -300mbar 4 bar 0.5A 40*66*95mm
