CMP-11 vacuum(air,gas) micro pump are well suited for transferring,evacuating and compressing air and neutral or corrosive gases as well as vapors.

Technical Features:
1.Uncontaminated flow.
2.Non-metallic construction.
3.Compact size.
4.Maintaince free.
5.High level of gas tightness thanks to the closed diaphragm surface and special sealing system.
6.Can operate in any installed position.

Various models


Voltage Free flow Max vacuum Max pressure Current Size
CMP-11A 3 VDC 0.8 L/min -500mbar 0.8 bar 0.4A 17.5*26.5*45mm
CMP-11B 3 VDC 1 L/min -700mbar 1.2 bar 0.7A 17.5*26.5*45mm
CMP-11E 3 VDC 0.5 L/min -300mbar 0.5 bar 0.2A 17.5*26.5*45mm
